ACOPower Mono Solar RV Kits

Power Your RV Adventures With The ACOPower Mono Solar RV Kits

Imagine the freedom of exploring the great outdoors without the worry of running out of power. With an ACOPower Mono Solar RV Kit, you can power your RV and enjoy all the comforts of home, even when you're off the grid.

These kits are equipped with high-efficiency mono solar panels that convert sunlight into clean, renewable energy. The panels are durable and weatherproof, so they can withstand the harshest conditions. The kits also include a powerful inverter that converts DC power from the solar panels into AC power that can be used to power your RV's appliances and electronics.

ACOPower Mono Solar RV Kits Features

High solar cell efficiency

Charge controllers efficiency reaches 80-90%, enable the solar panel to operate at its maximum power point, or more precisely, the optimum voltage and current for maximum power output.

Ultra-fast tracking speed

Manages the charging process of your RV's batteries in three distinct stages: bulk charging, absorption charging, and float charging, ensuring that your batteries are charged optimally, maximizing their lifespan and performance while preventing overcharging.

Reliable & Safe

Electronic protections: reverse current, overcharging, short-circuit and reversed polarity. Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for 25 years.

Smart APP Control

Remote monitoring and Bluetooth control, a programmable interface with a multi-function LCD for displaying system information, and accurate recognition and tracking capabilities.

Warranty & Support

• Panels: The solar panel itself comes with a 5-year workmanship warranty and a 25-year 85% output warranty.
• Solar Charge Controllers: The controller itself comes with a 1-year warranty.
• Accessories: 1-year material warranty

ACOPower Mono Solar RV Kits Specifications

ACOPOWER 100 WATTS ALL BLACK MONO SOLAR PANEL

• Maximum Power at STC (Pmax): 100W
• Maximum Operating Voltage (Vmp): 17.48V
• Maximum Operating Current (Imp): 5.71A
• Dimension: 1130x510x35mm / 44.5x20.1x1.4 in
• Open-Circuit Voltage (Voc): 22V
• Short-Circuit Current (Isc): 6.14A
• Operating Temperature: -40ºC to 85ºC
• Weight: 9.5kg / 20.9 lbs

ACOPOWER 200 WATTS ALL BLACK MONO SOLAR PANEL

• Peak Power (Pmax):200W
• Max Power Voltage(Vmp):20.4V
• Max Power Current(Imp):9.8A
• Weight:26.5 lb/12kg
• Peak Circuit Voltage(Voc):24.3V
• Short Circuit Current(Isc): 10.2A
• Wind resistance:2400pa
• Dimension: 54.72 x 27.56x 1.3 Inch

ACOPOWER 60A MPPT CHARGE CONTROLLER

• Nominal System Voltage: 12v/24v/36v/48v DC auto work
• Rated Charge Current: 60A
• Max. PV Open Circuit Voltage: 150V/138V
• Max. PV input power: 1125W/12V, 2250W/24V, 2812.5W/36V ,4500W/48V
• MPPT Voltage Range: (Battery Voltage+2V) ~72V
• Dimension:261*216*119mm
• Grounding: Common negative
• Battery Input Voltage Range: 8V～32V
• MPP voltage range:V(BAT)+2V～108V
• Rated Charge Power : 750W/12V, 1500W/24V, 2250W/36V ,3000W/48V
• RS485 Interface: 5VDC/200mA(RJ45)
• Installion Notes：First connect the battery；Then connect the load; Finally connect the solar panel.

ACOPOWER 50A MPPT SOLAR CHARGE CONTROLLER

• Nominal System Voltage: 12v/24v/36v/48v DC Auto
• Rated Charge Current: 50A
• Max. PV Open Circuit Voltage: 150V/138V
• MPP Voltage Range: V(BAT)+2V～108V
• Working temperature: -25℃～+50℃
• RS485 Interface: RS485(RJ45)
• Dimension: 261*216*119mm
• Grounding: Common negative Design
• Battery Input Voltage Range: 8V～68V
• Rated charge Power: 625W/12V 1250W/24V 1875W/36V 2500W/48V
• Battery type: Sealed(Default)/Gel/Flooded/User. Lead-acid batteries and Lithium-ion batteries
• Storage temperature: -20℃～+70℃
• Enclosure: IP33
• Terminals: 16mm2/6AWG

ACOPOWER MIDAS 40A MPPT SOLAR CHARGE CONTROLLER

• Nominal System Voltage: 12/24VDC Auto
• Rated Charge Current: 40A
• Max. PV Open Circuit Voltage: 100V (1) 92V (2)
• MPPT Voltage Range: (Battery Voltage+2V) ~72V
• Working temperature: -25℃～+50℃
• Terminals: Up to 6 AWG
• Dimension: 10x7.28x2.67 in / 255×185×67.8mm
• Grounding: Common negative
• Battery Input Voltage Range: 8V～32V
• Rated charge Power: 520W/12V 1040W/24V
• RS485 Interface: 5VDC/200mA(RJ45)
• Storage temperature: -20℃～+70℃
• Enclosure: IP33
• Weight: 3.75lbs / 1.7kg

ACOPOWER 30A MPPT SOLAR CHARGE CONTROLLER

• Nominal system voltage: 12/24VDC Auto
• Battery input voltage range: 8V～32V
• Max.PV input power: 12V/390W, 24V/780W
• Working environment temperature: -25℃～+50℃
• Grounding: Common negative
• Power Terminals: 6AWG(16mm2)
• Dimensions: 228x164x55mm
• Rated charge current: 30A
• Max.PV open circuit voltage: 100VDC
• MPP voltage range: V(BAT+2V)～72V
• Storage temperature range: -35℃～+80℃
• Communication: RS485
• Enclosure: IP30
• Weight: 1.2kg
