The EG4 12000XP V2 Off-Grid Inverter is designed to provide homeowners, RV enthusiasts, off-grid adventurers, and mobile business operators with dependable, high-capacity power. Delivering up to 12kW of split-phase output and handling up to 24kW of solar PV input, this inverter ensures uninterrupted energy wherever you need it. Its dual MPPT inputs, built-in breakers, and rapid 15–30ms UPS transfer switch provide seamless operation during outages or fluctuations, keeping critical systems online and running efficiently. With transformer-free efficiency, smart load control, and AC coupling capabilities, it minimizes energy loss while maximizing reliability and performance.
Whether you’re powering a full household, an RV on a cross-country trip, or an off-grid cabin, the EG4 12000XP V2 Off-Grid Inverter delivers smooth, consistent energy for every situation. Compared to typical alternatives, which often require heavier transformers and offer lower efficiency, this inverter combines portability with industrial-grade performance, giving you long-term reliability and lower energy costs.
Investing in the EG4 12000XP V2 Off-Grid Inverter means choosing reliability, long-term performance, and lower energy costs. Whether your priority is home backup, off-grid independence, or mobile power, this inverter ensures your devices stay running smoothly, giving you peace of mind and energy confidence. Step into smarter energy solutions with a system that works as hard as you do.
The EG4 12000XP V2 Off-Grid Inverter uses dual MPPT solar inputs to extract the most energy from your panels. This ensures faster battery charging, higher solar efficiency, and reliable power for homes, RVs, and off-grid adventures.
With a fast 15–30ms UPS transfer switch, your critical devices stay on instantly during blackouts. Sensitive electronics like computers, refrigerators, and lights remain uninterrupted, providing peace of mind for homeowners, RV users, and mobile business operators.
This inverter avoids heavy transformers, making it easier to install and transport. Its compact, lightweight design reduces energy loss, increases efficiency, and fits perfectly in homes, RVs, cabins, or mobile worksites without taking up extra space.
Smart load control monitors energy use and directs power to your most important devices first. This helps prevent overloads, reduces wasted electricity, lowers costs, and ensures that critical appliances always stay powered when you need them most.
Integrated WiFi and communication interfaces allow you to check inverter performance remotely. You can monitor solar input, battery status, and energy usage from your phone or computer, keeping your system under control even when you’re away from home or the worksite.
AC coupling makes it easy to connect the inverter with your current solar setup. Whether upgrading or expanding your system, this feature allows smooth integration, maximizing energy use from solar panels and batteries for reliable off-grid or backup power.
Peak shaving manages electricity demand during high-cost periods, lowering your energy bills. It ensures your essential loads continue running smoothly while making the most of solar and battery power, perfect for homeowners, RVers, off-grid cabins, and mobile businesses.
EG4 provides a 5-year warranty policy, ensuring the absence of defects in materials, workmanship, and performance during the warranty period.
EG4 12000XP V2 Off-Grid Inverter Specifications
|
|
|---|---|
| Nominal AC Voltage | 120/240VAC |
| Frequency (Grid | Generator) |
| Max Continuous AC Current (Grid | Generator) |
| Max AC Input Power | 24,000W |
| AC Bypass (Grid | Generator) |
| Recommended Generator Capacity | 6,000W – 15,000W |
| Output Voltage | 120/240VAC |
| Output Frequency | 60 Hz (Default) |
| Max Continuous Output Current | 50A @ 240VAC |
| Nominal Output Power (without PV) | 12,000W @ 240V |
| Nominal Output Power (with PV) | 12,000W @ 240V |
| Max Continuous Wattage | 12,000W (L1/L2) |
| Surge Capacity | 18,000W (5 sec) |
| Power Factor | 0.99 |
| Total Harmonic Distortion | <3% |
| Switching Time | <10 ms (Single) |
| No. of MPPTs (Inputs per MPPT) | 2 (2) |
| Max Input Current | 35A / 35A |
| Max Short Circuit Input Current | 44A / 44A |
| DC Input Voltage Range | 100 – 480VDC |
| Min Start Up Voltage | 100VDC |
| MPPT Operating Voltage Range | 120 – 385VDC |
| Nominal MPPT Voltage | 320VDC |
| Max Utilized PV Power | 24,000W (12,000W per MPPT) |
| Max Recommended PV Input | 28,000W (14,000W per MPPT) |
| Efficiency | 99% (MPPT) |
| Idle Consumption (Standby Mode) | <70W |
| Nominal Voltage | 48VDC |
| Battery Voltage Range | 46.4 – 60VDC |
| Max Charge / Discharge Current | 250A |
| Max Charge / Discharge Power | 12,000W |
| DC Cut-Off Voltage | 59VDC |
| Recommended Battery Capacity per Inverter | >400Ah |
| Max Parallel Connections | 6 |
| Protection Rating | IP20 |
| Communication Interface | RS485 / CANBus / WiFi |
| Operating Temperature (Full Load) | 32ºF – 113ºF (0ºC – 45ºC) |
| Storage Temperature | 5ºF – 140ºF (-15ºC – 60ºC) |
| Altitude | <6,561 ft (2,000 m) |
| Relative Humidity | 5 – 95% (Non-Condensing) |
| Typical Noise Emission | <60 dB |
| Cooling Method | Fan |
| Weight | 104.7 lbs (47.5 kg) |
| Depth | 5.9 in (150 mm) |
| Width | 20.9 in (530 mm) |
| Height | 34.25 in (870 mm) |
