When the grid goes down, your life shouldn't have to. The Mango Power S Pro 5000W Solar System Set is a complete, professional-grade solar solution engineered for homeowners, RVers, off-grid adventurers, and mobile business operators who demand reliable, high-output power without compromise. Built around the Mango Power S Pro microinverter one of the most efficient and intelligently designed microinverters on the market this system set delivers up to 5,000 watts of clean solar power with the kind of performance specs that solar professionals get genuinely excited about.
Whether you're fortifying your home against rolling blackouts, powering your RV adventure across the country, running a remote worksite, or building a fully off-grid homestead, this system was designed to meet you exactly where you are and keep up with whatever comes next.
At Outbound Power, we don't just sell solar equipment we help you find the right solution for your specific power needs. Our team understands the demands of home backup, mobile living, off-grid energy independence, and professional worksite power, and we're here to make sure your solar investment performs for decades, not just seasons.
The Single-Stage Cyclo microinverter skips the usual two-step conversion process. That means less energy wasted, more power delivered. You get more out of your panels every single day even in low light conditions.
With 97.0% CEC efficiency and 99.9% MPPT tracking, nearly every watt your panels produce becomes usable power. Your system constantly adjusts to changing sunlight so you never miss a generation opportunity.
The NEMA Type 6P sealed enclosure is dustproof, waterproof, and fanless. It runs reliably from -40°F to 149°F. No moving parts means fewer things that can break perfect for rooftops, RVs, and harsh outdoor environments.
Every microinverter comes with a 25-year warranty and a 219,000-hour design life. That matches the lifespan of your solar panels exactly. Install it once and trust it to keep working no costly early replacements needed.
The built-in Wi-Fi MESH network connects all 10 microinverters into one smart system. If one unit loses signal, the network reroutes automatically. Monitor real-time energy production panel by panel through the Mango Power app.
The touch-safe polymer housing uses Class II double insulation, so no grounding wires are needed. The units are 20% lighter than metal alternatives. Less wiring, less weight, and faster setup even for first-time installers.
Unlike string inverters where one shaded panel hurts the whole array, each microinverter operates on its own. A cloud over one panel does not affect the other nine. You get full output from every panel, always.
Mango Power provides a limited warranty policy, ensuring the absence of defects in materials, workmanship, and performance during the warranty period.
Mango Power S Pro 5000W Solar System Set Specifications |
|
|---|---|
| Commonly Used Module Power | 400W – 670W+ |
| Maximum Input Voltage | 60V |
| MPPT Voltage Range | 16 – 60V |
| Peak Power MPPT Voltage Range | 36 – 55V |
| Start-Up Voltage | 22V |
| Maximum Input Current | 16A |
| Maximum Input Short Circuit Current | 25A |
| Number of MPPTs | 1 |
| Number of Inputs per MPPT | 1 |
| Nominal Output Power | 500 VA |
| Maximum Continuous Output Current | 2.08 / 2.40 A |
| Nominal Output Voltage / Range | 240V (L-L) / 211–264V & 208V (L-L) / 183–228V |
| Nominal Frequency / Range | 60Hz / 55–65Hz |
| Power Factor Setting | 0.99 |
| Power Factor (Adjustable) | 0.8 Leading – 0.8 Lagging |
| Total Harmonic Distortion | < 3% |
| Maximum Units per Branch (12 AWG) | 7 |
| Maximum Units per Branch (10 AWG) | 11 |
| Peak Efficiency | 97.5% |
| CEC Efficiency | 97.0% |
| MPPT Efficiency | 99.9% |
| Night Power Consumption | < 50 mW |
| Operating Temperature Range | -40°C to +65°C |
| Storage Temperature Range | -40°C to +85°C |
| Dimensions (L × W × H) | 221.5 × 129.0 × 32.5 mm |
| Weight (without bracket) | 1.2 kg |
| Enclosure Rating | NEMA Type 6P / IP68 |
| Cooling | Natural Convection (Fanless) |
| Pollution Degree | III |
| Enclosure Protection Class | Class II Double-Insulated |
| Maximum Altitude | 4,000 m / < 13,123 ft |
| Noise Level | < 25 dB |
| Communication | Sub-1G |
| Indicator | 1 × LED |
| Communication | Sub-1G |
| Indicator | 1 × LED |
| Warranty | 25 Years |
