The Rich Solar 30 Amp Solar Charge Controller Flush Mount

The 30 Amp Solar Charge Controller Flush Mount is a high-quality and efficient device designed to regulate and manage the charging process of your solar panels. It is specifically designed for solar systems with a maximum current capacity of 30 amps, making it suitable for small to medium-sized solar installations.


    Rich Solar 30 Amp Solar Charge Controller Flush Mount Features

    • Flush mounted and embedded installation design
    • High quality and low failure rate components (ST/IR) to ensure the product lifetime
    • 3-Stage intelligent PWM charging: Bulk, Boost/Equalize and Float
    • Battery type: Sealed, Gel, Flooded
    • Real-time energy statistics feature
    • Battery temperature compensation feature
    • Digital LCD monitor for informative display of operational parameters and fault messages
    • Voltage drop and temperature compensation sampling interface design
    • RS485 communication port with Modbus protocol, and short circuit protection for 5V/200mA power supply
    • Multiple communication peripherals
    • Rated charging current at working temperature without de-rating
    • Extensive electronic protections
    • Monitor and set the parameters via PC software or APP


    What's In The Box

    • 1 x RICH SOLAR 30 Amp Solar Charge Controller Flush Mount


      Rich Solar 30 Amp Solar Charge Controller Flush Mount Specifications

      Electrical Specifications

      Nominal Voltage: 12/24VDC or Auto
      Battery Input Voltage Range: 8V~32V
      Rated Charge Current: 30A
      Max. PV Short Circuit Current: 30A
      Max. PV Open Circuit Voltage: 50V
      Battery Type: Sealed(default)/Gel/Flooded
      Self-consumption: ≤4.2mA/12V;≤2.6mA/24V
      Temperature Compensation Coefficient: -3mV/°C/2V(Default)
      Charge Circuit Voltage Drop: 0.21V

      Environmental Parameters

      Storage Temperature Range: -30°C~+80°C
      Working Environment Temperature: -20°C~+55°C(100% input and output)
      Relative Humidity: ≤95%, N.C.
      Enclosure: IP30
      Grounding: Common negative
      Altitude: 5000m
      Pollution Degree: PD2


      Mechanical Parameters

      Dimension(L×W×H): 178.5×105.5×48.3mm
      Mounting Dimension: 166.5×93.5mm
      Mounting Hole Size: Φ5mm
      Terminal: 16mm2/6AWG
      Recommended Cable: 6mm2/10AWG
      Net Weight: 0.31kg
