AIMS Power 3kW 24VDC Off-Grid Solar Kit | 720W Solar

AIMS Power introduces the new all-in-one solar kit for all of your off grid power needs. Whether you’re supplying power to a medium size appliance in an RV or small cabin, this solar kit includes all necessary products required and bundled for your convenience.

This 720 watt solar kit is most effective when used to power medium size devices such as pumps, tools, freezer/refrigerators, and electronics.  The 3000 watt 24 VDC inverter runs more efficiently and includes a built in charger to recharge the batteries when city or generator power is available.

This system is also able to use 720 watts of solar panels with the 30 amp charger at 24VDC.  The panels are covered in tempered glass to protect from hazardous weather. The PV wiring is protected against UV, water, ozone, fluids, oil, salt and general weathering. Each system comes with a wiring diagram upon purchase.

This kit is ideal for mid-size appliances, computers and CPAPs. Perfect for locations that need have access to a generator or shore power to recharge batteries using the inverter. The 24Vdc voltage runs more efficiently using less equipment. The solar panels provide a constant charge with sunlight and will recharge the batteries at 50% depletion in <7 hours.

All shipping costs are included in the sales price.

AIMS Power 3000 Watt 24VDC Off-Grid Solar Kit Features

• Easy to connect and use
• Works with medium size devices up to 3000 watts/ 20.8 AC amps
• Ideal for medium size appliances, tools, pumps or small compressors, electronics
• 24VDC more efficient

*The solar panel will recharge a 50% depleted 450 amp battery bank in 7.5 hours with full sunlight.*

What's In The Box

• 1 x 24 Volt 3000 watt pure sine inverter charger
• 6 x 120 watt monocrystalline solar panels @ 40SQ FT
• 1 x 3 string combiner box
• 1 x Disconnect switch
• 1 x 30 amp PWM flush mount solar charge controller
• 4 x 225 ah AGM deep cycle batteries – 6 volts
• 1 x 20 foot. PV extension wires male to female for solar panels to combiner box
• 1 x 100 foot PV wires for combiner box to disconnect switch
• 1 x Male and female MC4 for disconnect to charge controller
• 1 x 6 foot set wire from charge controller to battery bank
• 1 x 50 amp fuse kit with jumper for charge controller to battery bank
• 1 x 8 ft set of 4 AWG cable battery bank to inverter
• 4 x 1 foot jumper for fuse kit and battery series connection
• 1 x 150 amp inline fuse kit battery bank to inverter
• 1 x Battery Temperature Sensor
