The AIMS Power 6000 Watt 48 Volt Pure Sine Inverter Charger With Split Phase 120/240VAC Output Can Run a Smaller Home, Office or Large RV
The AIMS Power 6000 Watt 48 Volt Pure Sine Inverter Charger With Split Phase 120/240VAC Output is a low frequency inverter charger built for running a smaller whole house, a business office or a large RV. It is a strong fit for off-grid systems and emergency backup supplies. The 48 volt DC input performs with very little power loss, and AIMS Power notes a notable efficiency increase in large systems compared with 12 or 24 volt inverters. It combines a 6000 watt split phase pure sine inverter, a 60 amp four-stage charger that uses 240 volt grid power, and a seamless automatic transfer switch that turns your system into a true uninterruptible power supply when a battery bank is connected.
AIMS Power 6000 Watt 48 Volt Pure Sine Inverter Charger Features
Split Phase 120/240 Volt Pure Sine Output
Output is split phase at 120 and 240 volts AC, with voltage options of 100, 110, 120, 220, 230 and 240 volts. If you only need 120 volts, AIMS Power offers a separate 120 volt model, PICOGLF60W48V120V.
18,000 Watt Surge for 20 Seconds
Low frequency construction gives this inverter 3x surge capability, delivering 18,000 watts for 20 seconds and 6000 watts continuously. The AC direct connect terminal block makes it suited to permanent whole-house and office installations.
60 Amp Four-Stage Smart Charger
The built-in charger uses 240 volt grid power to charge your batteries. It charges gel, lead, AGM and lithium batteries, with 7 battery type settings and adjustable charge current from off to 20% to 100%. A battery temperature sensor is available.
Seamless Automatic Transfer for UPS-Style Backup
If grid power is lost, the automatic transfer switch moves your loads to battery power with a typical transfer time of 10 milliseconds. AIMS Power describes this as a true uninterruptible power supply for emergencies and natural disasters, with a battery bank required. Transfer is rated at 75 amps at 120 volts and 40 amps at 240 volts.
Auto Generator Start
Auto generator start mode can signal a generator to start and begin providing charge to the batteries. On 240 volt gensets, charging is through a separate charger, as noted by AIMS Power.
Auto Frequency Detection
Auto frequency detection provides the correct output frequency at 50 or 60 Hz, so the inverter can work with 50 Hz electronics and in many countries.
Battery Priority, Power Save and Protection
A battery priority selector lets you draw on your battery bank first. Optional 25 watt power save mode reduces idle consumption from 1.67 amps DC to under 0.83 amps DC. Resettable circuit breakers and marine-coated boards add protection, and an optional LCD remote panel shows abnormalities across the system so you know where to look.
Real-World Applications
Smaller whole-home backup. Keep essential 120 and 240 volt circuits running during outages.
Business offices. Provide UPS-style backup that switches to battery power automatically when the grid fails.
Large RVs. Run household-style split phase loads from a 48 volt battery bank.
Off-grid solar systems. Pair with a 48 volt battery bank and solar array, with auto generator start for backup charging.
How It Compares to Common Alternatives
Versus the 120 volt model. AIMS Power offers PICOGLF60W48V120V for 120 volt only systems. Choose this split phase version when you need 240 volt output.
Versus the 24 volt split phase model. The 6000 watt 24 volt version uses a 24 volt bank and an 85 amp charger. This 48 volt model draws less current for the same power, which AIMS Power notes is more efficient in large systems.
Versus the 8000 watt 48 volt model. The 8000 watt model adds capacity and ETL listing to UL 1741 standards at a heavier 132 pounds. This 6000 watt model weighs 74 pounds.
Is This Inverter Charger the Right Fit
-
System voltage. It requires a 48 volt battery bank, with a minimum start voltage of 44 volts DC.
-
Charging source. The charger uses 240 volt grid power, so confirm your AC source.
-
Pass-through limits. Transfer is rated at 75 amps at 120 volts and 40 amps at 240 volts.
-
Weight and size. At 74 pounds and 28.25" x 8.88" x 7.5", plan for a solid mounting location.
This may be a good fit if
- You want to power a smaller home, office or large RV with split phase output
- You run or plan a 48 volt battery bank
- You want automatic UPS-style backup during outages
- You want auto generator start capability
Common Questions
Does It Work as a UPS?
Yes. With a battery bank connected, the automatic transfer switch moves loads to battery power when grid power is lost, with a typical transfer time of 10 milliseconds.
Can It Start My Generator?
It includes an auto generator start mode that can signal a generator to start and provide charge to the batteries.
Which Batteries Can It Charge?
The 60 amp charger supports gel, lead, AGM and lithium batteries, with 7 battery type settings.
What Warranty Does It Carry?
AIMS Power backs this inverter charger with a 3 year warranty and lifetime tech support.
What's Included
- 1 x AIMS Power 6000 Watt 48 Volt Pure Sine Inverter Charger With Split Phase 120/240VAC Output
- 1 x Instruction Manual
Efficient Split Phase Backup for 48 Volt Systems
The AIMS Power 6000 Watt 48 Volt Pure Sine Inverter Charger With Split Phase 120/240VAC Output combines split phase pure sine power, a 60 amp charger, automatic transfer and auto generator start in one unit. At Outbound Power, we help customers design backup and off-grid systems around their real loads. Contact our team and we will help you plan yours.
AIMS Power 6000 Watt 48 Volt 120/240VAC Pure Sine Inverter Charger Specifications
|
| Continuous Output Power |
6000 Watts |
| Surge Rating |
18,000 Watts (20 Seconds) |
| Output Waveform |
Pure Sine / Same as Input (Bypass Mode) |
| Output Voltage |
100–110–120 / 220–230–240Vac, Split Phase 120 and 240Vac |
| Nominal Efficiency |
>88% (Peak) |
| Line Mode Efficiency |
>95% |
| Output Frequency |
50Hz ±0.3Hz / 60Hz ±0.3Hz (Auto Frequency) |
| Typical Transfer Time |
10ms (Max) |
| THD |
<10% |
| Ambient Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Nominal Input Voltage |
48VDC |
| Minimum Start Voltage |
44VDC |
| Low Battery Alarm |
42VDC–44VDC |
| Low Battery Trip |
40VDC–42VDC |
| High Voltage Alarm |
64VDC |
| Low Battery Voltage Restart |
53.2VDC |
| Idle Consumption |
1.67A DC |
| Power Saver Mode Idle Consumption |
<0.83A DC |
| Charger Rate |
60A, Four-Stage Smart Charger |
| Charger Current Adjustment |
Off–20%–100% |
| Charger Output Voltage |
Depends on Battery Type |
| Compatible Batteries |
Gel, Lead, AGM, Lithium (7 Battery Type Settings) |
| Automatic Transfer Switch (Bypass) |
75A at 120Vac / 40A at 240Vac, 10ms (Max) |
| Other Features |
Battery Priority Selector, AC Direct Connect Terminal Block, Marine Coated, Auto Gen Start, Resettable Circuit Breakers, Remote Panel Available, Battery Temp Sensor Available |
| Unit Size (L × W × H) |
28.25" × 8.88" × 7.5" |
| Unit Weight |
74 lbs |
| Shipping Size (L × W × H) |
30.5" × 14.25" × 13.75" |
| Shipping Weight |
84 lbs |
| Warranty |
3 Year Warranty and Lifetime Tech Support |
AIMS Power 6000 Watt 48 Volt Pure Sine Inverter Charger Manual
