The EcoFlow WAVE 3 Battery Locks Under Your WAVE 3 and Adds 1024Wh for 2-8 Hours of Cordless Comfort
The EcoFlow WAVE 3 Battery is EcoFlow's WAVE 3 Add-on Battery, a 1024Wh LiFePO4 battery designed to power the EcoFlow WAVE 3 Portable Air Conditioner and Heater away from an outlet. The air conditioner sits on top of the battery and clicks into place.
It suits WAVE 3 owners who camp, travel by road or want cooling and heating where there is no wall power. It also charges your devices from USB-C and USB-A ports.
EcoFlow WAVE 3 Battery Features
1024Wh LFP Battery Rated for 4000 Cycles
The battery stores 1024Wh (51.2V, 20Ah) in LFP (LiFePO4) cells, rated to keep 80% or more of their capacity after 4000 cycles. Maximum output is 858W.
Detachable Design That Locks to the Air Conditioner
Line the air conditioner up with the marks on top of the battery, set it down and push it forward until it clicks, then plug in the included WAVE 3 Add-on Battery Cable. Once connected, turning on either unit turns on the other. To separate them, press the unlock button and slide the air conditioner back, so you can carry or stow the battery on its own.
Four Ways to Recharge
Connect the battery to the air conditioner's XT150 port and plug the air conditioner into a wall outlet. The XT60i port takes up to 400W of solar at 11-60V and 13A, or 12V/24V car power at up to 200W with the included car charging cable. An EcoFlow 500W Alternator Charger connects to the XT60i port, and an 800W Alternator Charger connects to the XT150 port for two-way charging and discharging with the car battery, after setup in the app. Maximum input is 1000W.
USB-C and USB-A Outputs
The USB-C output delivers up to 140W and supports PD3.1, QC3.0 and UFCS (36W). The USB-A output delivers up to 18W with QC3.0. A press of the power button turns the USB ports off or back on.
Real-World Applications
Camping. Run the air conditioner at a tent site with no hookups.
Road trips. Recharge from the car outlet with the included cable, from an EcoFlow Alternator Charger while you drive, or from up to 400W of solar at your stop.
Device charging. Charge a phone, tablet or other USB device from the USB-C and USB-A ports.
How It Compares to Common Alternatives
Versus running the WAVE 3 from the wall. On wall power, the air conditioner stays near an outlet. With this battery attached, it runs for EcoFlow's listed 2-8 hours wherever you set it up.
Versus a DELTA power station. The WAVE 3 can also run from an EcoFlow DELTA Max, DELTA 2 or DELTA 3 series power station with an Extra Battery Cable. The add-on battery is designed for the WAVE 3, locks to it and includes its connection cable.
Is This Battery the Right Fit
-
Made for the WAVE 3. EcoFlow designed it to power the WAVE 3 portable air conditioner.
-
Weight. It weighs 21.4 lbs (9.7 kg) and measures 20.3 x 11.1 x 4.4 in.
-
Keep it dry. It is rated IP65, but EcoFlow says not to get it wet or immerse it. In rain or near water, protect it with a waterproof bag.
-
Solar cable. Solar charging needs an EcoFlow Solar to XT60i Charging Cable, sold separately.
-
No flights. EcoFlow says not to carry it onto a plane.
This may be a good fit if
- You own a WAVE 3 and want to use it away from an outlet
- You want to recharge from solar, a car or an Alternator Charger
- You want USB charging for your devices at camp
Common Questions
How Long Will It Run My WAVE 3?
EcoFlow lists a battery runtime of 2-8 hours. While it runs, the WAVE 3 display shows the battery level and remaining time.
What Solar Panels Can I Use?
Keep the total open circuit voltage within 60V and the total short circuit current within 13A, up to 400W. Connect with an EcoFlow Solar to XT60i Charging Cable.
How Should I Store It?
Every 3 months, charge it fully and then discharge it to 60%. Store it between 14°F and 113°F (-10°C to 45°C). Leaving it uncharged or unused for more than 6 months voids the warranty.
What's Included
- 1 x EcoFlow WAVE 3 Add-on Battery
- 1 x EcoFlow WAVE 3 Add-on Battery Cable
- 1 x EcoFlow Car Charging Cable
- 1 x Safety Instructions, Quick Start Guide and Warranty Card
Longer Cooling and Heating Away From an Outlet
The EcoFlow WAVE 3 Battery adds 1024Wh of LFP storage and a listed 2-8 hours of runtime to your WAVE 3. If you have questions about charging or runtime, the Outbound Power team is happy to help.
EcoFlow WAVE 3 Battery Specifications
|
| General |
| Model |
EF-WA-E01-3 |
| Designed For |
EcoFlow WAVE 3 |
| Capacity and Battery |
| Capacity |
1024Wh (51.2V, 20Ah) |
| Cell Chemistry |
LFP (LiFePO4) |
| Cycle Life |
80%+ capacity after 4000 cycles |
| Battery Runtime |
2-8 hours |
| Output |
| Maximum Output |
858W |
| USB-C Output |
5/9/12/15V 3A, 20V/28V 5A, 140W max |
| USB-C Protocols |
UFCS (36W), PD3.1, QC3.0 |
| USB-A Output |
5V 2.4A, 9V 2A, 12V 1.5A, 18W max |
| USB-A Protocol |
QC3.0 |
| Extra Battery Port |
XT150 |
| Charging Input |
| Maximum Input |
1000W |
| Solar/Car Charging Port |
XT60i |
| Solar Input |
11-60V, 13A max, 400W max |
| Car Input |
12V/24V, 8A max, 200W max |
| Wall Charging |
Through the WAVE 3 XT150 connection |
| Environment |
| Discharge Temperature |
14°F to 122°F (-10°C to 50°C) |
| Charge Temperature |
32°F to 113°F (0°C to 45°C) |
| Storage Temperature |
14°F to 113°F (-10°C to 45°C) |
| IP Rating |
IP65 |
| Operating Altitude |
Under 2000 m (6562 ft) |
| Size and Weight |
| Dimensions |
20.3 x 11.1 x 4.4 in (516 x 281 x 111 mm) |
| Net Weight |
21.4 lbs (9.7 kg) |
