The Epoch Batteries 12V 105Ah (1.34kWh) LiFePO4 Battery Adds Self-Heating and Bluetooth to a Group 24 Footprint
The Epoch 12105A-H is an Essential Series lithium iron phosphate battery rated at 12.8V nominal and 105Ah, for 1.34kWh (1,344Wh) of stored energy in a BCI Group 24 case that weighs 22.1 lb. It combines internal heating for cold-weather charging, Bluetooth monitoring with a shunt built into the BMS, and an IP54 enclosure.
It's made for compact 12V deep-cycle systems: RV, camper and van house power, marine house power, 12V trolling motors, solar storage and backup for small inverters. It fits many Group 24 installations, but it is not a drop-in replacement for every lead-acid or AGM battery, and it is not cranking-rated.
Epoch Batteries 12V 105Ah (1.34kWh) LiFePO4 Battery Features
Self-Heating for Charging Below Freezing
The cells never accept charge current while any battery temperature reading is below 0°C (32°F). When a charger supplying at least 0.5A is connected, that incoming current powers internal heating pads, and charging resumes automatically at 5°C (41°F). The heater never uses stored battery energy, so it does not warm the battery during discharge or storage. With heating, the charge range is -20°C to 55°C (-4°F to 131°F).
Bluetooth Monitoring With a Built-In Shunt
The free Epoch Li-Ion app for iOS and Android shows state of charge, voltage, current, temperature and battery status. A shunt built into the BMS measures current to 0.2A accuracy on discharge, so no external shunt is needed. The Bluetooth PIN is printed on the battery's lid and can be changed in the app.
105A Continuous and 200A Peak Discharge
Epoch rates it for 105A maximum continuous discharge, with 52.5A (0.5C) recommended for sustained loads, and 200A for up to 10 seconds. It accepts up to 100A continuous charge, 50A recommended. Size loads, cables and fuses to the 105A continuous rating, not the 200A peak.
Group 24 Footprint at 22.1 lb
The case measures 10.25 x 6.75 x 9.00 in (260.4 x 171.5 x 228.6 mm) and weighs 22.1 lb (10.02 kg), with M8 female terminals. Epoch offers a battery tray sized for this model as an accessory, sold separately.
IP54 Enclosure and Smart BMS
The IP54 enclosure is dust protected and splash resistant for protected RV, marine, mobile and outdoor compartments. It is not waterproof or submersible. The BMS guards against overcharge, over-discharge, over-current, short circuit (600A at 500µs) and high or low temperature, with a low-voltage disconnect at 10.0V.
Long Cycle Life and an 11-Year Limited Warranty
Epoch rates it for 4,000 cycles with at least 80% of capacity remaining, with no watering or acid service. It carries an 11-year limited warranty: 3 years of free replacement, then 40% off MSRP on a replacement battery through Year 11. Register within 90 days of purchase for full coverage.
Real-World Applications
RV, camper and van house power. Run 12V DC loads and a small inverter, and keep charging in freezing weather from a converter, solar controller or DC-to-DC charger programmed for LiFePO4.
Marine house power and trolling motors. Power electronics, pumps and lighting, or a 12V trolling motor (24V and 36V motors through matched series banks) where the motor's current stays within the battery ratings.
Solar and off-grid storage. Epoch's planning estimates use 80% of nominal energy, about 1,075Wh (84Ah) per battery: about 10.8 hours at 100W, 4.3 hours at 250W, 2.2 hours at 500W and 8.4 hours at a 10A DC load.
Larger banks. Connect up to 4 in series for a 48V system class or up to 4 in parallel for 420Ah, to a maximum 4S4P bank of 16 batteries and about 21.50kWh.
How It Compares to Common Alternatives
Versus the Epoch Eco 100Ah. Both are Group 24 LiFePO4 batteries in the same case size. The Essential 105Ah adds internal heating, Bluetooth monitoring and an 11-year limited warranty, while the Eco 100Ah has no app or heater, a 6-year warranty and a 4,500+ cycle rating. Both start with 3 years of free replacement.
Versus a Group 24 lead-acid or AGM battery. This battery needs no watering or acid service, and the app shows state of charge without a separate monitor. Check tray fit, terminal clearance, cable size and charger profile first, and never use lead-acid equalization, desulfation or repair modes on it.
Versus a cranking battery. This is a deep-cycle battery for house loads. For engine starting, use a cranking-rated battery.
Is This 12V Battery the Right Fit
-
Series and parallel. Up to 4 in series and up to 4 in parallel (4S4P maximum) with matched 12105A-H batteries of similar age, condition and firmware, all at the same state of charge. Never mix them with lead-acid or other models.
-
Charger settings. LiFePO4 profile, 14.2–14.4V bulk/absorption, ending at C/20 (5.25A) or 15 minutes, whichever comes first, float disabled (preferred) or 13.3–13.6V, re-bulk 13.2V, equalization and temperature compensation off. Keep all sources combined within 100A, and use a DC-to-DC charger for alternator charging.
-
Cold charging. If your charger has its own battery temperature sensor, set its limits to 0°C to 55°C (32°F to 131°F) unless it has approved cold-charge logic, and allow time for the heater before assuming a fault.
-
Installation. Mount it upright and secured, fit a fuse or DC-rated breaker as close as practical to the positive terminal, and torque the M8 terminals to 8–12 N·m (71–106 in-lb). Epoch recommends a full charge before first use.
This may be a good fit if
- You have a Group 24 tray in an RV, van or boat
- You charge in freezing weather
- You want to check the battery from your phone
- Your loads stay within 105A continuous
Common Questions
Will the Heater Drain the Battery?
No. The heater runs only while a charger is connected and supplying at least 0.5A, and it draws from that incoming current, never from stored energy. While the cells warm, the app may show little or no charge current, which can be normal.
How Cold Can It Charge?
The heating system is tested to -20°C (-4°F) and rated for external ambient temperatures down to -40°C (-40°F). The cells themselves never charge below 0°C; the heater warms them first.
Is It Waterproof?
No. IP54 means dust protected and splash resistant. Do not submerge, pressure-wash or install it where standing water can collect.
How Should I Store It?
Store it clean and dry at 0°C to 35°C (32°F to 95°F) at about 50% state of charge or higher, with loads and chargers disconnected. Check it at least every 3 months, since the warranty excludes batteries left uncharged for more than three months.
What's Included
- 1 x Epoch 12V 105Ah Essential Series LiFePO4 Battery (12105A-H)
Cold-Weather Group 24 Power You Can Check From Your Phone
The Epoch Batteries 12V 105Ah (1.34kWh) LiFePO4 Battery gives a Group 24 tray 1.34kWh, self-heating for charging in freezing weather and Bluetooth monitoring with a built-in shunt. If you have questions about tray fit, charger settings or building a bank, the Outbound Power team is happy to help.
Epoch 12105A-H Specifications
|
| Electrical |
| Model |
12105A-H |
| Series |
Essential Series |
| Battery type |
Heated Bluetooth deep-cycle (not cranking-rated) |
| Group size |
BCI Group 24 |
| Chemistry |
LiFePO4 (lithium iron phosphate) |
| Cell type |
Prismatic LiFePO4 |
| Cell configuration |
4S1P |
| Nominal voltage |
12.8V |
| Nominal capacity |
105Ah at 0.2C (21A) |
| Stored energy |
1,344Wh (1.34kWh) nominal |
| Runtime planning energy |
About 1,075Wh (84Ah), 80% of nominal |
| Operating voltage range |
10.0–14.6V |
| Maximum charge voltage |
14.6V |
| Internal resistance |
≤30 mΩ |
| Self-discharge |
≤3% per month |
| Cycle life |
4,000 cycles with ≥80% capacity remaining |
| Charge and Discharge |
| Maximum continuous discharge |
105A |
| Recommended discharge current |
52.5A (0.5C) |
| Peak discharge |
200A for up to 10 s |
| Maximum continuous charge |
100A, all sources combined |
| Recommended charge current |
50A |
| Series connection |
Up to 4 (up to 48V system class) |
| Parallel connection |
Up to 4 (up to 420Ah) |
| Maximum configuration |
4S4P, 16 batteries (about 21.50kWh) |
| Bank batteries |
Matched 12105A-H, same state of charge |
| Recommended Charge Settings |
| Charger type |
LiFePO4 profile (no lead-acid, AGM or gel profiles) |
| Bulk / absorption voltage |
14.2–14.4V |
| Absorption end |
C/20 (5.25A) or 15 min, whichever comes first |
| Float voltage |
Disabled (preferred) or 13.3–13.6V |
| Re-bulk voltage |
13.2V |
| Equalization |
Disabled |
| Temperature compensation |
0 mV/°C (off) |
| Charger temperature limit |
0 to 55°C (32 to 131°F) unless approved cold-charge logic |
| BMS high-voltage cutoff |
14.6V |
| SOC recalibration voltage |
14.6V |
| Alternator charging |
DC-to-DC charger programmed for LiFePO4 |
| Temperature |
| Charge, with heating |
−20 to 55°C (−4 to 131°F) |
| Cell charge acceptance |
Only at or above 0°C (32°F) |
| Low-temperature charge cut-off |
0°C (32°F) |
| Charging resumes |
Automatically at 5°C (41°F) |
| Heater activation |
Charger connected, supplying at least 0.5A |
| Heater power source |
Incoming charge current only |
| Heating system tested to |
−20°C (−4°F) |
| Rated external ambient |
Down to −40°C (−40°F) |
| Discharge |
−20 to 60°C (−4 to 140°F) |
| Storage (recommended) |
0 to 35°C (32 to 95°F) |
| Long-term storage |
About 50% state of charge or higher |
| Operating altitude |
Below 3,000 m (about 9,840 ft) |
| BMS and Protection |
| Overcharge |
Disconnects or limits operation |
| Over-discharge |
Low-voltage disconnect 10.0V; reconnect 12.0V |
| Over-current |
Protects against sustained loads above ratings |
| Short circuit |
Rapid cutoff, rated 600A at 500µs |
| Temperature |
High- and low-temperature disconnects |
| External protection |
Fuse or DC-rated breaker close to the positive terminal |
| Communication and Monitoring |
| Bluetooth |
Built in |
| App |
Epoch Li-Ion (iOS and Android) |
| App readings |
State of charge, voltage, current, temperature, status |
| Current sensing |
BMS-integrated shunt, 0.2A accuracy on discharge |
| External shunt |
Not needed |
| Bluetooth PIN |
Printed on the battery's lid; changeable in the app |
| Size and Weight |
| Dimensions (L x W x H) |
10.25 in x 6.75 in x 9.00 in (260.4 x 171.5 x 228.6 mm) |
| Weight |
22.1 lb (10.02 kg) |
| Terminals |
M8 female (M8 bolt) |
| Terminal torque |
8–12 N·m (71–106 in-lb) |
| Mounting orientation |
Upright |
| Case material |
ABS / PC blend, UL94-V0 |
| Enclosure |
IP54 (IEC 60529) |
| Water and dust |
Dust protected, splash resistant |
| Not rated for |
Submersion, pressure washing or standing water |
| Battery tray |
Epoch tray for 12105A-H / 12100-ECO, sold separately |
| Certifications |
| Cells |
UL 1642, IEC 62619:2022 (cell level) |
| Product |
CE, RoHS |
| Transport |
UN 38.3, Class 9 |
| Warranty |
| Warranty |
11-year limited warranty |
| Years 1–3 |
Free replacement |
| Years 4–11 |
40% off MSRP on a replacement battery |
| Registration |
Within 90 days of purchase for full coverage |
