The Epoch Batteries 12V 334Ah (4.28kWh) LiFePO4 Battery Pairs 300A Output With Victron CAN, Self-Heating and Bluetooth for Indoor RV and Van Installs
The Epoch 12334A-MC is the 12V 334Ah MC in Epoch's Essential Series: a lithium iron phosphate battery rated at 12.8V nominal and 334Ah, for 4.28kWh (4,275Wh) of stored energy in one powder-coated steel case weighing 75 lb. It delivers 300A continuous, heats itself for cold-weather charging, balances its cells with a 2A active balancer, and reports to the Epoch Li-Ion app and to Victron GX systems over CAN-bus.
It's made for high-capacity 12V house power in RVs, camper vans, skoolies, off-grid cabins and solar banks, installed in a dry, protected interior space. Its IP21 enclosure is for indoor use only, it connects in parallel only, and it is not a cranking battery.
Epoch Batteries 12V 334Ah (4.28kWh) LiFePO4 Battery Features
300A Continuous for Large Inverter Systems
Epoch rates it for 300A maximum continuous discharge, with 150A recommended for daily use, and 600A for up to 10 seconds for appliance and inverter start-up surges. At 12.8V, 300A is about 3,840W of DC output before inverter losses, enough for a properly designed 3,000W-class inverter system. Size by the inverter's DC input current, not its AC output.
Victron CAN Communication
Wired to a Victron Cerbo GX or Ekrano GX with a straight-through RJ45 patch cable, the host battery becomes the controlling BMS. With DVCC on, it sets the charge voltage and current limits for MultiPlus, MPPT and Orion chargers. Batteries in a bank link over RJ45 patch cables and negotiate their host or node role automatically, with no DIP switches or addresses, and the GX shows the bank as one battery.
Self-Heating for Cold-Weather Charging
An internal heating film lets it charge from -20°C to 55°C (-4°F to 131°F). With a charger connected and the cells below 0°C (32°F), the heater warms them and the BMS blocks charge current until they are above 5°C (41°F), which can take up to 60 minutes in deep cold. The heater runs only while a charger is connected.
Bluetooth Monitoring and 2A Active Balancing
The free Epoch Li-Ion app for iOS and Android shows state of charge, voltage, current, cell voltages, temperatures, cycle count, heater status and protection history. The 2A active balancer moves charge between the four cells across the full state-of-charge range to keep their voltages matched.
300A Charging
It accepts up to 300A continuous charge per battery from all sources combined, with up to 167A (0.5C) recommended. A charger below 167A is suitable; it simply takes longer.
Steel Case Built for Dry Interior Spaces
The powder-coated steel case measures 15.35 x 8.07 x 11.02 in (390 x 205 x 280 mm), with M10 female terminals. It is rated IP21, which protects against fingers and vertically dripping water only, so install it upright in a dry, protected space such as under a bed, in a dinette bench or in an electrical cabinet.
Long Cycle Life and an 11-Year Limited Warranty
Epoch rates it for 4,500+ cycles with no watering or acid service. It carries an 11-year limited warranty: 3 years of free replacement, then 40% off MSRP on a replacement battery through Year 11. Register within 90 days of purchase for full coverage.
Real-World Applications
RV boondocking with large loads. Run air conditioners, microwaves, induction cooking and residential refrigerators through a properly designed inverter system, within 300A continuous. Epoch's planning estimates use 80% of nominal energy (3,420Wh): about 3.4 hours at 1,000W and 1.1 hours at 3,000W.
Camper vans and skoolies. Put 4.28kWh under a bed, in a bench or in a cabinet. At lighter loads, Epoch estimates about 34.2 hours at 100W and 6.8 hours at 500W.
Victron systems. Pair it with a Cerbo GX or Ekrano GX so the battery sets charge limits through DVCC for MultiPlus, MPPT and Orion chargers.
Off-grid cabins, solar and backup. Build parallel 12V banks with LiFePO4-compatible charge controllers and inverter chargers, or use it for protected marine house power.
How It Compares to Common Alternatives
Versus a bank of smaller 12V batteries. One 4.28kWh battery replaces several smaller batteries and their parallel wiring, with one BMS and active balancing across its four cells. If you need more capacity, 4 batteries in parallel are validated plug and play.
Versus a splash-rated outdoor battery. This model's IP21 steel case has seams that are not gasketed and is for dry indoor installs only. If the battery must sit in an exterior bay, an engine bay or on an open deck, this model is not the right choice.
Versus a cranking battery. This is a deep-cycle house battery. For engine starting, use a cranking-rated battery.
Is This 12V Battery the Right Fit
-
Parallel only. Up to 4 matched 12334A-MC batteries in parallel are validated plug and play (1,336Ah, 17.10kWh); banks of up to 16 need Epoch design support for fusing and busbars. Series connection is not approved, so it must not be used to build 24V, 36V or 48V systems. Bring each battery within 0.05V of the others before connecting.
-
Charger settings. 14.2–14.4V bulk/absorption, ending at C/20 (about 16.7A) or 15 minutes, whichever comes first, float disabled (preferred) or 13.3–13.6V, re-bulk 13.2V, equalization and temperature compensation disabled. With a GX and DVCC, the battery sets the limits; Victron chargers without a GX need a user-defined 12V LiFePO4 profile in VictronConnect.
-
Indoor location. IP21 is not weatherproof or waterproof. Keep it out of engine bays, exterior bays, trailer tongues, open decks and anywhere it can be sprayed, rained on or submerged.
-
Installation. 75 lb (34 kg), so use proper lifting technique and mounting hardware rated for the weight. Torque the M10 terminals to 13–17 N·m (115–150 in-lb), and place a DC-rated main fuse or breaker within 18 in (45 cm) of the positive terminal.
This may be a good fit if
- You run a Victron Cerbo GX or Ekrano GX system
- You need 300A for a 3,000W-class inverter
- Your battery space is dry and indoors
- You charge in freezing weather
Common Questions
Will the Heater Drain the Battery While Boondocking?
No. The heater runs only while a charging source such as solar, shore power or a DC-to-DC charger is connected. With no charger connected it stays off, and the battery can still discharge down to -20°C (-4°F) without heating.
What Cable and Fuse Does Epoch Recommend?
For a single battery at 12V, Epoch's guidance runs from 2 AWG with a 150A fuse for loads up to 100A, to 4/0 AWG with a 350A Class T fuse for loads up to the 300A BMS maximum. Use larger cable for runs longer than 6 ft (2 m) or in hot locations.
How Far Does Bluetooth Reach?
The BMS allows one Bluetooth connection at a time. Metal compartments reduce range, so stay within about 10 ft (3 m).
How Should I Store It?
Store it at 0°C to 35°C (32°F to 95°F) at about 50% state of charge or higher, with loads and chargers disconnected. Check it at least every 3 months, since batteries left uncharged for more than three months are excluded from warranty coverage.
What's Included
- 1 x Epoch 12V 334Ah MC Essential Series LiFePO4 Battery (12334A-MC)
- 2 x M10 Stainless Terminal Bolts With Washers
High-Output 12V House Power for Victron Builds
The Epoch Batteries 12V 334Ah (4.28kWh) LiFePO4 Battery gives an RV or van 4.28kWh with 300A continuous output, Victron CAN communication, self-heating and Bluetooth monitoring in one indoor-rated steel case. If you have questions about Victron setup, inverter sizing or parallel banks, the Outbound Power team is happy to help.
Epoch 12334A-MC Specifications
|
| Electrical |
| Model |
12334A-MC |
| Series |
Essential Series |
| Battery type |
Heated Bluetooth deep-cycle with Victron CAN (not a cranking battery) |
| Chemistry |
LiFePO4 (lithium iron phosphate) |
| Cell type |
Grade-A prismatic LiFePO4 |
| Cell configuration |
4S1P |
| Nominal voltage |
12.8V |
| Nominal capacity |
334Ah |
| Stored energy |
4,275Wh (4.28kWh) nominal |
| Runtime planning energy |
About 3,420Wh (80% of nominal) |
| Operating voltage range |
10.0–14.6V |
| Maximum charge voltage |
14.6V |
| Cell balancing |
2A active balancing |
| Cycle life |
4,500+ cycles |
| Charge and Discharge |
| Maximum continuous discharge |
300A (about 3,840W DC at 12.8V) |
| Recommended daily discharge |
150A or less |
| Peak discharge |
600A for up to 10 s (start-up surges) |
| Inverter class (Epoch guidance) |
Properly designed 3,000W-class system |
| Maximum continuous charge |
300A per battery, all sources combined |
| Recommended charge current |
Up to 167A (0.5C) |
| Recommended charge, banks |
Up to 50% of bank capacity (334A 2P, 501A 3P, 668A 4P) |
| Series connection |
Not approved for this model |
| Parallel connection |
Up to 4 validated plug and play |
| Larger banks |
Up to 16 in parallel with Epoch design support |
| Maximum 4P bank |
1,336Ah / 17.10kWh at 12.8V |
| Bank matching |
Same model, age and capacity, within 0.05V before connecting |
| Recommended Charge Settings |
| Charger type |
12V LiFePO4 or programmable profile |
| Bulk / absorption voltage |
14.2–14.4V |
| Absorption end |
C/20 (about 16.7A) or 15 min, whichever comes first |
| Float voltage |
Disabled (preferred) or 13.3–13.6V |
| Re-bulk voltage |
13.2V |
| Equalization |
Disabled |
| Temperature compensation |
0 mV/°C (disabled) |
| BMS high-voltage cutoff |
14.6V |
| Victron GX (DVCC) |
Battery sets charge voltage and current limits |
| Victron without GX |
User-defined 12V LiFePO4 profile in VictronConnect expert mode |
| Alternator charging |
DC-to-DC charger |
| Temperature |
| Charge, with heating |
−20 to 55°C (−4 to 131°F) |
| Low-temperature charging |
Heater on below 0°C (32°F) with a charger connected |
| Charging resumes |
Above 5°C (41°F) |
| Heater warm-up time |
Up to 60 min in deep cold |
| Heater power |
Runs only while a charger is connected |
| Discharge |
−20 to 60°C (−4 to 140°F) |
| Storage (recommended) |
0 to 35°C (32 to 95°F) |
| Long-term storage |
About 50% state of charge or higher |
| BMS and Protection |
| Battery management |
Built-in smart BMS |
| Protection |
Overcharge, over-discharge, over-current, short circuit |
| Temperature |
High- and low-temperature disconnects |
| Main fuse location |
Within 18 in (45 cm) of the positive terminal |
| Cable and fuse at 300A |
4/0 AWG (95 mm²), 350A Class T fuse |
| Cable and fuse at 150A |
1/0 AWG (50 mm²), 200A fuse |
| Communication and Monitoring |
| Bluetooth |
Built in |
| App |
Epoch Li-Ion (iOS and Android) |
| App readings |
SOC, voltage, current, cell voltages, temperatures |
| App history |
Cycle count, heater status, protection history |
| Bluetooth connections |
One at a time |
| Bluetooth range |
About 10 ft (3 m) in metal compartments |
| Victron communication |
Victron CAN-bus (GX / DVCC) |
| Victron GX devices |
Cerbo GX, Ekrano GX |
| CAN profile |
CAN-bus BMS, 500 kbit/s |
| GX device name |
DRIFT |
| Data ports |
CAN, Battery Link A, Battery Link B |
| Bank linking |
RJ45 patch cables (Cat5e, Cat6 or Cat7, not crossover) |
| Host and node roles |
Negotiated automatically; no DIP switches |
| Size and Weight |
| Dimensions (L x W x H) |
15.35 in x 8.07 in x 11.02 in (390 x 205 x 280 mm) |
| Weight |
75 lb (34 kg) |
| Terminals |
M10 female |
| Terminal torque |
13–17 N·m (115–150 in-lb) |
| Mounting orientation |
Upright; do not invert during operation |
| Case material |
Powder-coated steel |
| Enclosure |
IP21 (IEC 60529) |
| Water and dust |
Fingers and vertically dripping water only |
| Installation |
Dry, protected indoor locations only |
| Certifications |
| Certifications |
UL 1642, UL 9540A, IEC 62619:2022 |
| Compliance marks |
CE, RoHS |
| Transport |
UN 38.3, Class 9 |
| Warranty |
| Warranty |
11-year limited warranty |
| Years 1–3 |
Free replacement |
| Years 4–11 |
40% off MSRP on a replacement battery |
| Registration |
Within 90 days of purchase for full coverage |
