AIMS Power 1500 Watt 12 Volt Pure Sine Power Inverter With USB Port & Remote Port

AIMS Power 1500 Watt 12 Volt Pure Sine Power Inverter Overview

Power inverters have become a staple in businesses and homes around the world due to intermittent brown and black-outs. AIMS pure sine wave power inverters provide reliable transformation of DC power from a battery (such as the one in a car or RV) into AC power that can then be used to run lights, computers, printers, televisions, medical equipment* and a broad range of appliances.

And when it comes to selecting an inverter, it’s helpful to know that AIMS pure sine wave inverters represent the most technologically advanced, lightweight, compact and diverse inverters on the market to help ensure the widest use of applications. For over a decade, AIMS Power has consistently delivered the broadest range of sizes to accommodate virtually every power requirement.

Advantages of a pure sine inverter:

• Equipment runs more efficiently
• Motors run cooler
• Cleaner power
• Ideal for power tool chargers, laser printers, electric shavers, microwaves, variable speed motors, TV’s, medical equipment

To select the right inverter, first determine what devices you would need to run in the event of a power outage. Then, select the appropriate inverter that can carry the combined wattage requirements of these devices. Please see our tech support section for start up averages for all devices. At AIMS, you’ll discover our inverters range from 75 watts up to 50,000 watts – more than enough to power nearly every application imaginable.

AIMS Power 1500 Watt 12 Volt Pure Sine Power Inverter Features

• 1500W continuous power
• 15 volt DC Input
• Pure sine wave
• USB Port
• Triple AC receptacles
• On/off switch
• Over temperature indicator
• Overload protection
• Low battery voltage warning/shutdown
• High input voltage protection with automatic shutdown
• Over load indicator
• Short circuit protection
• Dual cooling fans thermally controlled
• AC output short circuit protection
• ETL listed to UL 458 Standards

Warranty & Support

• Instruction manual
• Free 2 year tech support
• 2 Year Warranty Parts and Labor

AIMS Power 1500 Watt 12 Volt Pure Sine Power Inverter Specifications

• Continuous output power 1500 watts
• Surge power 3000 watts
• Input voltage range 9.5-16v
• Output voltage 120v
• DC input 12v
• Output wave form Pure sine wave 60Hz (THD ≤3%)\
• Efficiency 90%
• USB Output 5VDC, Max, 1A
• Input over-voltage shutdown 16 ± 0.5VDC
• Input under-voltage shutdown 9.5 ± 0.5VDC
• Input under-voltage alarm 9.8 ± 0.3VDC
• Over temperature protection 149 ± 8°F
• Over-load protection 1700W ± 200W
• No Load Consumption 0.8A
• Working Temperature 32-104°F
• Storage temperature 14-113°F
• Intelligent cooling (the cooling fan will start running when the case temperature reaches 104°F)
• Dimension (L x W x H) 15.875 x 8.375 x 3.875 in.
• Unit Weight 10 lbs.
• Shipping weight 12 lbs.
• Remote port for optional remote

Manual

• AIMS Power 1500 Watt 12 Volt Pure Sine Power Inverter Manual
