The AIMS Power 10,000 Watt 48 Volt Pure Sine Inverter Charger Delivers Split Phase Backup Power With Efficient 48 Volt Performance
The AIMS Power 10,000 Watt 48 Volt Pure Sine Inverter Charger is a low frequency, split phase power system built for emergency backup in homes, businesses, and recreation locations, as well as large off-grid installations. Its 48 volt DC input runs with very little power loss, offering a notable efficiency advantage over 12 or 24 volt systems at this scale. With 10,000 watts of continuous 120/240 volt AC power, a 30,000 watt surge for up to 20 seconds, a 100 amp multi-stage charger, and an automatic transfer switch, it is ready to keep an entire home or facility running when the grid goes down.
AIMS Power 10,000 Watt 48 Volt Pure Sine Inverter Charger Features
10,000 Watts Continuous With 30,000 Watts of Surge
Low frequency construction provides three times its continuous rating in surge for up to 20 seconds, so large motors, pumps, and compressors start with confidence.
Split Phase Output for 120 and 240 Volt Loads
Output covers 100/110/120 volts and 220/230/240 volts AC, supporting both everyday circuits and 240 volt appliances.
100 Amp Multi-Stage Smart Charger
The charger supports gel, lead, AGM, and lithium batteries with eight battery charger settings, keeping your bank healthy whether you charge from the grid or a generator.
Automatic Transfer With 10 Millisecond Typical Switchover
When utility power is lost, the built-in automatic transfer switch moves your loads to battery power with a typical transfer time of 10 milliseconds.
Power Save Mode and Battery Priority
A selectable 25 watt power save mode drops idle consumption from 150 watts to 35 watts. Battery priority mode lets you favor stored or solar energy over other AC sources.
Marine Coated, International Ready, and Remote Capable
Marine-coated boards protect against humidity, dust, and dirt, and over temperature protection with dual thermally controlled fans handles heat. The SW4 switch selects 50 or 60 Hz output for use with electrical systems worldwide, and a remote panel is available.
Real-World Applications
Home and business backup. AIMS Power notes the most common use is emergency backup power for homes, businesses, and recreation locations.
Off-grid solar. Pair with a 48 volt battery bank charged by solar panels for clean, renewable power.
Cabins and remote properties. Provide whole-property split phase power where the grid does not reach.
International installations. 50/60 Hz selection and multiple output voltages broaden where it can be used.
How It Compares to Common Alternatives
Versus the 12,000 watt model. AIMS Power offers a 12,000 watt version with more output and a larger charger if you need extra capacity.
Versus a modified sine 10,000 watt inverter. AIMS Power notes its modified sine model has fewer features at a lower price. This pure sine inverter charger adds charging, transfer switching, and split phase output.
Versus a standby generator. A battery-based system runs silently with no fuel on site and can recharge from solar.
Is This Inverter Charger the Right Fit
-
Installation. At 145.5 pounds with split phase output, professional installation is strongly recommended.
-
Battery bank. Plan a 48 volt battery bank sized for your loads and runtime.
-
Idle consumption. 150 watts at idle, or 35 watts in power saver mode.
-
Operating temperature. Ambient range is 14°F to 122°F.
This may be a good fit if
- You want whole-home or business backup with 120/240 volt output
- You are building a large 48 volt off-grid or solar system
- You need strong surge for large motor loads
- You want automatic transfer and smart charging in one unit
Common Questions
Can It Run Internationally?
Yes. AIMS Power notes it can output 120 or 220/230/240 volts and 50 or 60 Hz via the SW4 switch.
What Charger Rate Does It Have?
The multi-stage smart charger delivers up to 100 amps.
How Much Power Does It Use at Idle?
Idle consumption is 150 watts, or 35 watts in power saver mode.
What Warranty Does It Carry?
The AIMS Power product page lists both a 3 year warranty with lifetime tech support and a 1 year warranty, so please confirm current warranty terms with us before purchase.
What's Included
- 1 x AIMS Power 10,000 Watt 48 Volt Pure Sine Inverter Charger
- 1 x Instruction Manual
Whole-Property Power, Efficiently Delivered
The AIMS Power 10,000 Watt 48 Volt Pure Sine Inverter Charger combines efficient 48 volt operation, split phase output, and heavy-duty surge for dependable backup and off-grid power. At Outbound Power, we help customers design complete systems with batteries, solar, and professional installation in mind. Reach out to our team to plan yours.
AIMS Power 10,000 Watt 48 Volt Pure Sine Inverter Charger Specifications
|
| Continuous Output Power |
10,000 Watts |
| Surge Rating |
30,000 Watts (20 Seconds) |
| Output Waveform |
Pure Sine / Same as Input (Bypass Mode) |
| Output Voltage |
100–110–120Vac / 220–230–240Vac Split Phase |
| Nominal Efficiency |
>88% (Peak) |
| Line Mode Efficiency |
>95% |
| Output Frequency |
50Hz ±0.3Hz / 60Hz ±0.3Hz (SW4 Selectable) |
| Typical Transfer Time |
10ms (Max) |
| THD |
<10% |
| Ambient Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Nominal Input Voltage |
48.0Vdc |
| Low Battery Alarm |
42.0Vdc–44.0Vdc |
| Low Battery Trip |
40.0Vdc–42.0Vdc |
| High Voltage Alarm |
64.0Vdc |
| Low Battery Voltage Restart |
52.0Vdc |
| Idle Consumption |
150 Watts |
| Power Saver Mode Idle Consumption |
35 Watts |
| Charger Rate |
100A Multi-Stage Smart Charger |
| Compatible Batteries |
Gel, Lead, AGM, Lithium (8 Charger Settings) |
| AC Connection |
Terminal Block |
| AC Outlets |
2 Outlets (Dual-Plug Receptacle) |
| Other Features |
Automatic Transfer Switch, Battery Priority Selector, Marine Coated, Dual Thermally Controlled Fans, Remote Panel Available |
| Unit Size (L × W × H) |
23.3" × 16.3" × 7.9" |
| Unit Weight |
145.5 lbs |
| Shipping Size (L × W × H) |
30" × 21.25" × 15.25" |
| Shipping Weight |
190 lbs |
| Warranty |
Confirm Current Terms Before Purchase (AIMS Lists Both 1 Year and 3 Year Terms) |
