Rich Solar 400 Watt Solar Kit

The Rich Solar 400 Watt Solar Kit Pairs Two MEGA 200 Panels With a BRAVO 30 MPPT Controller for Expandable 12V Charging

The Rich Solar 400 Watt Solar Kit is a complete 12V solar charging kit built around two MEGA 200 monocrystalline panels and a BRAVO 30 30A MPPT charge controller. It produces about 1.4kWh per day with 4 peak sun hours, enough to keep an RV, trailer, boat or cabin battery bank charged while you are off the grid.

Everything needed to go from the panels to your battery comes in the box: Z brackets for both panels, a cable entry housing for a clean roof pass-through, a 30 ft panel-to-controller cable set, a 10 ft controller-to-battery cable set and an inline fuse. Add a 12V battery, and an inverter if you want AC power, to finish the system.

Rich Solar 400 Watt Solar Kit Features

Two MEGA 200 Monocrystalline Panels

Each MEGA 200 panel produces 200W from high-efficiency monocrystalline cells under anti-reflective tempered glass and an anodized aluminum frame. They perform well in low light, have 14 pre-drilled mounting holes, and carry a 25-year output warranty and 10-year workmanship warranty.

BRAVO 30 MPPT Charge Controller

The BRAVO 30 uses an MPPT algorithm with up to 99.5% tracking efficiency and 98% peak conversion efficiency, so more of the panels' power reaches your battery. It auto-detects 12V or 24V systems and supports GEL, AGM, flooded, calcium, LiFePO4 and custom battery profiles.

Built-In Bluetooth and Clear Display

An LCD and LED display shows solar input and battery status at a glance, and built-in Bluetooth lets you monitor the system from the RICH SOLAR app. An optional remote meter and temperature sensor are available.

Full System Protection

The controller protects against over-voltage, reverse polarity, short circuits and over-temperature. The included 15A inline fuse adds circuit protection on the panel side.

Room to Grow

The BRAVO 30 is rated for about 500W of solar on a 12V system and 1,000W on a 24V system. That leaves room to add another compatible Rich Solar panel later as your needs grow.

Real-World Applications

RVs and travel trailers. Keep house batteries charged for lights, fans, the water pump and a 12V fridge while boondocking.

Boats. Maintain house batteries at the mooring and while cruising.

Cabins and sheds. Run lighting, a small fridge and electronics without running power lines.

Vans and overland vehicles. Pair the kit with a lithium battery for quiet, fuel-free charging.

How It Compares to Common Alternatives

Versus buying components separately. The kit bundles matched panels, a controller, cables, brackets and a fuse, so you do not have to work out wire sizes and connectors yourself.

Versus a 200W kit. Twice the panel power roughly doubles daily harvest. That makes the 400W kit a better fit for larger battery banks or campers who use a fridge and inverter every day.

Versus a PWM kit. An MPPT controller like the BRAVO 30 converts excess panel voltage into charging current, typically harvesting more energy than a PWM controller, especially in cool weather.

Is This Kit the Right Fit

• Battery. The kit does not include a battery. It charges 12V lead-acid, AGM, gel or LiFePO4 batteries.
• AC power. Add an inverter if you want to run household appliances from the battery.
• Roof space. Each MEGA 200 panel measures 58.7 x 26.8 x 1.2 inches.
• Daily energy. Plan on about 1.4kWh per day with 4 peak sun hours. Actual output depends on location, season, tilt and shading.

This may be a good fit if

• You want a complete solar charging kit for a 12V RV, trailer, boat or cabin
• You already have a battery bank or plan to add one
• You want app monitoring and MPPT efficiency
• You want room to add another panel later

Common Questions

Does the Kit Include a Battery or Inverter?

No. This is a solar charging kit. It includes the panels, controller, mounting brackets, cables and fuse. The battery and inverter are sold separately.

Can I Use This Kit With a Lithium Battery?

Yes. The BRAVO 30 has a LiFePO4 charging profile and works with other lithium and lead-acid battery types.

Can I Add More Panels Later?

Yes. The BRAVO 30 is rated for about 500W of solar at 12V and up to 1,000W at 24V. Stay within the controller's input voltage and current limits.

How Are the Panels Wired?

The panels have MC4 leads and can be wired in series or parallel. Follow the BRAVO 30 manual for your battery voltage and cable run.

What's Included

• 2 x Rich Solar MEGA 200 12V 200W Solar Panels (RS-M200)
• 1 x Rich Solar BRAVO 30 30A MPPT Charge Controller (RS-MPPT30PB)
• 2 x Mounting Z Bracket Sets, 4 Brackets per Set (RS-ZB4C)
• 1 x Cable Entry Housing (RS-C2B)
• 1 x 15A Inline Fuse Holder With Fuse (RS-SC15F)
• 1 x 30 ft 10 AWG Solar Cable Set, Panel to Controller (RS-30101)
• 1 x 10 ft 10 AWG Battery Cable Set, Controller to Battery (RS-1010)

A Complete 400W Solar Charging Kit

The Rich Solar 400 Watt Solar Kit gives you matched panels, an efficient Bluetooth MPPT controller and all the cables and brackets needed for a clean 12V solar install. At Outbound Power, we help customers pick the right batteries and inverters to complete their systems. If you have questions, our team is happy to help.
