Sol-Ark 12K-2P Hybrid Inverter System

Sol-Ark 12K-2P Hybrid Inverter System Gives You Flexible Power Control

The Sol-Ark 12K-2P Hybrid Inverter System is an all-in-one hybrid power system designed to manage energy between solar, batteries, the utility grid, loads, and a generator. It combines an inverter, charger controller, and display with remote monitoring in one pre-wired system. With support for grid-tied, off-grid, and battery backup applications, the Sol-Ark 12K-2P gives homeowners and power-system planners a practical way to coordinate multiple energy sources from one system.

Sol-Ark 12K-2P Hybrid Inverter System Features

13,000W Maximum PV Input For Flexible Solar System Planning

The Sol-Ark 12K-2P supports up to 13,000W of PV power at STC, giving you substantial solar input capacity for a hybrid power setup. Its PV input operates across a nominal voltage range of 175–425V, with a 500V maximum input voltage. The system also provides two MPP trackers with two PV strings per MPPT.

• 13,000W maximum allowed PV power at STC
• 175–425V nominal PV voltage range
• 500V maximum input voltage
• 2 MPP trackers
• 2 PV strings per MPPT

Hybrid Energy Management So You Can Coordinate Multiple Power Sources

A hybrid inverter needs to do more than convert electricity. The Sol-Ark 12K-2P is designed to manage power to and from solar, batteries, the grid, loads, and a generator. That makes it suitable for systems where energy may come from more than one source and where controlling how those sources are used matters.

The system supports grid-tied operation, off-grid operation, and battery backup applications. It also provides DC and AC coupling capabilities for applicable system designs.

9,000W Continuous AC Output For Demanding Backup Loads

The Sol-Ark 12K-2P provides up to 9,000W of maximum continuous real power. Its nominal AC voltage options include 120/240V, 120/208V, and 220V, while the grid frequency is 50/60Hz. For off-grid operation, the inverter can provide up to 16,000VA of peak apparent power for 10 seconds at 240V and up to 25,000VA for 100 milliseconds.

Maximum grid passthrough current is 63A, while maximum output current is 37.5A. These figures give customers useful information for evaluating the inverter against their specific electrical system requirements.

48V Battery Support For Different Storage Strategies

The battery side of the Sol-Ark 12K-2P is designed around a nominal 48V DC battery system, with an operating voltage range of 43–63V. The system supports both lithium and lead-acid battery technologies, with a stated capacity range of 50–9,900Ah.

Maximum battery charge and discharge current is 185A. The charging controller uses three-stage charging with equalization, while grid-to-battery charging efficiency is rated at 96.0%.

Smart Energy Modes For More Control Over Grid Usage

The Sol-Ark 12K-2P includes several operating modes intended to give users greater control over how available energy is used. Grid-tied mode can be used to sell power and reduce electric bills, while Meter Zero Mode is designed to zero electric bill usage without a smart meter. Time-of-Use operation allows solar and batteries to be used to minimize grid power consumption.

The system also includes a programmable Smart Load Mode, giving system designers another option for managing loads according to the intended application.

Integrated Monitoring And Controls For Easier System Management

The Sol-Ark 12K-2P includes a touchscreen interface along with Wi-Fi and LAN communication. The pre-wired system also includes a display with remote monitoring. For battery management, an integrated current shunt provides accurate state-of-charge percentage information, while communication with lithium batteries is supported through CANBus and RS485.

Parallel Capability For Larger System Designs

When a single inverter is not enough for the planned system, the Sol-Ark 12K-2P can be stacked with up to 9 units in parallel. This capability can be relevant for system designs requiring more inverter capacity. Customers should confirm the appropriate configuration and system requirements before purchase.

Real-World Applications For The Sol-Ark 12K-2P

Home Backup Power For Greater Energy Flexibility

The Sol-Ark 12K-2P can serve as the central inverter component in a battery backup system, coordinating solar, batteries, grid power, loads, and a generator. Its 9,000W maximum continuous real-power rating provides a substantial amount of available AC output for an appropriately designed system.

Off-Grid Solar Systems For Independent Power Planning

For off-grid applications, the system can manage solar and battery power while providing AC output for connected loads. Its battery support, PV input capacity, and off-grid peak apparent power specifications make it a system worth considering when designing an off-grid energy solution.

Grid-Tied Solar For Managing Solar And Grid Energy

The Sol-Ark 12K-2P also supports grid-tied operation. Features such as Grid-Tied Mode, Meter Zero Mode, and Time-of-Use operation provide different ways to manage the relationship between solar production, battery storage, and grid power.

How The Sol-Ark 12K-2P Compares To Smaller Power Solutions

Portable power stations and smaller inverter systems can be useful for limited loads and temporary applications, but the Sol-Ark 12K-2P is designed around a more integrated hybrid energy architecture. It connects solar input, battery storage, grid power, loads, and generator power within one system rather than functioning simply as a standalone portable battery.

It is also different from a conventional fuel-powered generator because its energy-management role includes solar and battery inputs as well as grid and generator connections. The right choice depends on the customer's required output, battery configuration, solar array, electrical system, and intended application.

Is The Sol-Ark 12K-2P Right For Your System

The Sol-Ark 12K-2P may be a good fit if you are planning a hybrid solar and battery system and want an inverter capable of coordinating multiple energy sources. Its specifications are particularly relevant to customers evaluating higher-capacity residential, off-grid, or backup power configurations.

This May Be A Good Fit If:

• You need an all-in-one hybrid inverter system.
• You are planning a solar system with up to 13,000W of allowed PV power at STC.
• You need up to 9,000W of maximum continuous real power.
• You want support for 48V lithium or lead-acid batteries.
• You need grid-tied, off-grid, or battery backup functionality.
• You want the option to parallel up to 9 units.
• You want Wi-Fi and LAN communication with remote monitoring.

Before purchasing, confirm your required battery configuration, solar array design, AC voltage, electrical requirements, and any installation-related details for your specific project.

Common Questions About The Sol-Ark 12K-2P

What Is The Sol-Ark 12K-2P?

It is a pre-wired hybrid inverter system that includes an inverter, charger controller, and display with remote monitoring. It can manage power from solar, batteries, the grid, loads, and a generator.

How Much Solar Power Can The Sol-Ark 12K-2P Accept?

The maximum allowed PV power is 13,000W at STC. The system has two MPP trackers and two PV strings per MPPT.

What Batteries Does The Sol-Ark 12K-2P Support?

The system supports lithium and lead-acid battery technologies. Its nominal battery voltage is 48V, with an operating range of 43–63V.

Can Multiple Sol-Ark 12K-2P Units Be Used Together?

Yes. The Sol-Ark 12K-2P is stackable with up to 9 units in parallel. Customers should confirm the required configuration for their specific project.

Does The Sol-Ark 12K-2P Include Remote Monitoring?

Yes. The system includes a display with remote monitoring, as well as Wi-Fi and LAN communication.

What’s Included

• 1 x Inverter
• 1 x Charger Controller
• 1 x Display With Remote Monitoring
• 1 x External Temperature Sensor
• 1 x Wi-Fi And LAN Communication

Build Your Power System With Outbound Power

The Sol-Ark 12K-2P Hybrid Inverter System is designed for customers who want to bring solar, battery storage, grid power, loads, and generator input together within one hybrid power system. With substantial PV input capacity, 9,000W maximum continuous real power, 48V battery support, multiple operating modes, and parallel capability, it provides a flexible foundation for carefully planned energy systems.

At Outbound Power, we focus on helping customers select power equipment based on the actual requirements of their project—not simply a list of impressive numbers. Review your loads, battery requirements, solar design, and electrical configuration carefully, then choose the Sol-Ark 12K-2P when its capabilities align with your power goals.
