The AIMS Power 190 Watt Monocrystalline Solar Panel With Aluminum Frame is a versatile performer built with tempered glass and a strong surface to stand up to harsh weather. High light-transmission cells and textured glass make for a more efficient panel, and a built-in bypass diode minimizes power drop caused by shade. With pre-drilled holes in its aluminum frame, it installs easily on homes, vehicles, RVs, and industrial applications, and its 10.16 amp operating current makes it a strong producer for 12 volt charging systems.
Monocrystalline cells with 21.69% cell efficiency and 19.16% module efficiency convert sunlight into power efficiently, while textured glass improves light capture.
The panel is capable of producing up to 3 watts over its 190 watt rated capacity.
A 3.2 mm tempered glass front and sturdy aluminum frame protect the panel. It is rated for 6000Pa snow loads, 3600Pa wind loads, and hail up to 45 mm at 30.7 meters per second.
A 10 amp bypass diode helps reduce output loss when part of the panel is shaded.
Pre-drilled mounting holes simplify installation, and 35 inch cable leads give you flexibility in routing wiring.
Home solar. Build or expand a solar array for backup or supplemental power.
RVs and vehicles. Where roof space allows, a 190 watt panel delivers substantial charging current for house batteries.
Off-grid cabins. Combine several panels for a dependable off-grid power source.
Industrial applications. AIMS Power lists industrial uses among its applications.
Versus multiple 100 watt panels. A single 190 watt panel can reduce the number of panels, mounts, and connections needed for the same output.
Versus larger residential panels. Higher-wattage residential panels often run at higher voltages. This panel's 18.7 volt operating voltage suits 12 volt systems.
Versus flexible panels. Tempered glass and a rigid frame provide stronger protection for permanent installations.
A practical way to size an array is to estimate your daily energy use in watt hours, then divide by the average peak sun hours in your area. That gives a rough idea of how many watts of panels you need before accounting for real-world losses from heat, shading, and wiring. Our team is happy to run those numbers with you.
This may be a good fit if
Operating voltage (Vmp) is 18.7 volts, operating current (Imp) is 10.16 amps, open circuit voltage (Voc) is 22.44 volts, and short circuit current (Isc) is 10.92 amps.
The cable leads are 35 inches long.
Each panel weighs 26.5 pounds.
Yes. Panels can be wired in series to raise voltage or in parallel to raise current. Keep the combined voltage and current within your charge controller's input ratings, and use proper fusing or a combiner box for larger arrays.
AIMS Power provides a 25-year limited warranty, with power output guaranteed at 91.2% for 12 years and 80.6% for 25 years.
The AIMS Power 190 Watt Monocrystalline Solar Panel With Aluminum Frame combines efficient cells, durable construction, and easy mounting for reliable solar power. At Outbound Power, we help customers design solar arrays and choose the right charge controllers and batteries to match. Reach out to our team for help sizing your system.
AIMS Power 190 Watt Solar Panel Specifications |
|
|---|---|
| Maximum Power | 190 Watts |
| Operating Voltage (Vmp) | 18.7 Volts |
| Operating Current (Imp) | 10.16 Amps |
| Open Circuit Voltage (Voc) | 22.44 Volts |
| Short Circuit Current (Isc) | 10.92 Amps |
| Solar Cell | 156 mm × 52 mm Monocrystalline |
| Number of Cells | 36 (12 × 3) |
| Front Glass Thickness | 3.2 mm Tempered Glass |
| Temperature Coefficient of Isc | -0.048%/°C |
| Temperature Coefficient of Voc | -0.29%/°C |
| Temperature Coefficient of Pm | -0.37%/°C |
| Temperature Range | -40°C to +80°C |
| Power Tolerance | 0 to +3 Watts |
| Surface Maximum Load Capacity | 6000Pa Snow, 3600Pa Wind |
| Allowable Hail Load | 45mm at 30.7m/s |
| Bypass Diode Rating | 10A |
| Cell Efficiency | 21.69% |
| Module Efficiency | 19.16% |
| Cable Length | 35" |
| Dimensions | 59 1/16" H × 26 11/16" W × 1⅛" D |
| Weight | 26.5 lbs |
| Warranty | 25-Year Limited (91.2% Output at 12 Years, 80.6% at 25 Years) |
