The EcoFlow DELTA Pro Ultra Portable Solar Kit Pairs 7200W of Home Backup Power With Folding 400W Solar Panels
The EcoFlow DELTA Pro Ultra Portable Solar Kit combines one DELTA Pro Ultra inverter and one 6144Wh LFP battery with one to four EcoFlow 400W Portable Solar Panels. The inverter delivers 7200W of pure sine power at 120V and 240V and accepts up to 5.6kW of solar input.
It suits homeowners who want strong outage backup they can expand later, and owners of cabins, workshops and off-grid buildings. This page offers four kit sizes, from the one-panel Core Kit to the four-panel Pro Kit.
EcoFlow DELTA Pro Ultra Portable Solar Kit Features
7200W at 120V and 240V From One Inverter
The inverter supplies 7200W through six AC outlets: four 120V 20A outlets, one 120V 30A outlet and one 120/240V 30A outlet. EcoFlow lists a 10.8kW peak for 10 seconds for resistive loads such as water heaters. For compressor appliances like air conditioners and heat pumps, keep the combined rating within 120A LRA or 20A RLA per unit.
A 6144Wh LFP Battery That Can Grow
The DELTA Pro Ultra Battery stores 6144Wh in LFP cells and keeps 80% or more state of health after 3,500 cycles at 0.5C and 77°F (25°C). One inverter takes up to five batteries, which EcoFlow puts at about 30kWh. With a Smart Home Panel 2, three inverters and 15 batteries reach about 90kWh.
0 ms Online UPS for Sensitive Electronics
Plugged into a wall outlet, the power station passes grid power to your devices and switches to the battery automatically in an outage. The online UPS outlets switch in 0 ms and the backup UPS outlets in under 20 ms, so EcoFlow recommends the online UPS outlets for devices that need 0 ms switching.
Two Solar Inputs Totaling 5.6kW
The High-PV input takes 80–450V at up to 15A and 4000W, and the Low-PV input takes 30–150V at up to 15A and 1600W. You can use either input or both, and combine solar with wall or generator charging. A PV switch turns solar charging on and off.
Folding EcoFlow 400W Portable Solar Panels
Each panel is rated 400W (±10W) under standard test conditions, with a 48V open circuit voltage and MC4 connectors. It folds into a protective case that doubles as a kickstand, propping the panel at 40° to 80°. EcoFlow rates the panel body IP68 in lab testing, but keep the junction box and connections out of water.
Wall, Generator and EV Charging
The AC charging input takes 100–120V at 15A or 200–240V at 12.5A, and a speed switch sets the charging rate. EcoFlow notes that its AC Generator Charging Adapter is required for generator charging. With the EcoFlow EV X-Stream Adapter, sold separately, it charges from an EV charger at up to 7.2kW.
App Control and Cold-Weather Heating
The EcoFlow app connects by Wi-Fi or Bluetooth to set charge and discharge limits, a backup reserve, timers and TOU mode. Storm Guard charges it to 100% when severe weather is forecast. The battery heats itself below 32°F (0°C), and heating while charging needs at least 250W of input.
Real-World Applications
Outage backup. Plug in a refrigerator, lights and 240V appliances directly, or connect to your home circuits through a Smart Home Panel 2 or a transfer switch.
Cabins and off-grid buildings. Keep the power station indoors and set the folding panels out in the sun.
Garages and workshops. The 120V 30A and 120/240V 30A outlets supply up to 30A for heavier tools and equipment.
EV and 50A appliances. Connect one or two sets to the EcoFlow 50 Amp Hub to charge a car or run other NEMA 14-50 plug appliances.
How It Compares to Common Alternatives
Versus fewer panels. EcoFlow's series table lists 800W of panel power for two 400W panels, 1200W for three and 1600W for four. A single panel suits the Low-PV input, while four panels in series need the High-PV input.
Versus rigid roof panels. Portable panels fold away and need no mounting. The DELTA Pro Ultra also accepts third-party panels with MC4 connectors, but arrays on or in buildings need an NEC rapid shutdown function and a qualified installer.
Versus a gas generator. A gas generator needs fuel, makes engine noise and runs outdoors. The DELTA Pro Ultra stores energy from the sun, the wall or an EV charger and stays under 30 dB in most scenarios.
Is This Solar Kit the Right Fit
-
Weight. The inverter weighs about 70.8 lb (32.1 kg) and the battery about 111.3 lb (50.5 kg). EcoFlow recommends two people to carry it.
-
Indoor placement. It is rated IP54 with its covers closed. Keep it out of rain and humid areas, on a hard, flat surface.
-
Solar wiring. Each solar input allows up to 15A, and EcoFlow does not recommend parallel wiring. High-PV input charging cables are not included with the power station.
-
Home connection. Wiring it into your home must be done by a licensed electrician.
-
Storage. Leaving it uncharged or unused for more than 6 months voids the warranty.
This may be a good fit if
- You want 7200W at 120V and 240V from one unit
- You want to start at 6144Wh and add batteries later
- You want solar panels you can fold and store
- You have indoor space for a 27.2 x 18.9 in footprint
Common Questions
Which Solar Input Do the Panels Use?
One panel's 48V open circuit voltage falls inside the Low-PV input's 30–150V range. In series, EcoFlow lists two panels at 96V and three at 144V for either input, and four panels at 192V for the High-PV input only. Turn the PV switch off before connecting or disconnecting panels.
Can I Add More Batteries Later?
Yes. One inverter supports up to five DELTA Pro Ultra Batteries on the included portable stand. With 3 or more batteries, EcoFlow advises fitting the EcoFlow Fixing Metal Tab, sold separately.
What Warranty Does It Have?
EcoFlow lists a 5-year warranty on the inverter and a 5-year warranty on the battery. The 400W Portable Solar Panel manual lists a 12-month warranty.
What's Included
- 1 x EcoFlow DELTA Pro Ultra Inverter
- 1 x EcoFlow DELTA Pro Ultra Battery
- 1 x EcoFlow Portable Stand
- 4 x EcoFlow Supporting Legs
- 4 x M6x20 Screws
- 4 x EcoFlow Side Mount Casters
- 1 x EcoFlow Disassembly and Assembly Tool
- 1 x EcoFlow Solar to Low-PV Port Charging Cable
- 1 x EcoFlow AC Charging Cable
- 1 x EcoFlow Battery Connection Cable
- 1 x User Manual and Warranty Card
- 1, 2, 3 or 4 x EcoFlow 400W Portable Solar Panel (depending on the kit you choose)
- With Each Panel: 1 x Protective Case and Kickstand, 4 x Snap Hooks, 1 x Solar Charging Cable, 1 x User Manual and Warranty Card
Solar Backup That Grows With Your Home
The EcoFlow DELTA Pro Ultra Portable Solar Kit brings together 7200W of 120/240V output, a 6144Wh LFP battery, 0 ms online UPS outlets and folding 400W solar panels. If you have questions about which kit size fits your home, cabin or shop, the Outbound Power team is happy to help.
EcoFlow DELTA Pro Ultra Portable Solar Kit Specifications
|
| General |
| Inverter Model |
EFYJ751-PCS-US |
| Battery Model |
EFYJ751-BP |
| Core Kit |
1 x 400W Portable Solar Panel |
| Plus Kit |
2 x 400W Portable Solar Panels |
| Max Kit |
3 x 400W Portable Solar Panels |
| Pro Kit |
4 x 400W Portable Solar Panels |
| Capacity and Battery |
| Battery Capacity |
6144Wh (102.4V, 60Ah) |
| Cell Chemistry |
LFP |
| Cycle Life |
80%+ state of health after 3,500 cycles |
| Cycle Test Conditions |
0.5C/0.5C at 77°F (25°C) |
| Voltage Protection |
Overvoltage, low voltage |
| Current Protection |
Overload, overcurrent, short circuit |
| Temperature Protection |
Overtemperature, low temperature |
| Battery Self-Heating |
Starts automatically below 32°F (0°C) |
| AC Output |
| Rated AC Output |
7200W total, 120/240V, 60Hz, pure sine wave |
| Peak Output |
10.8kW for 10 seconds |
| AC Outlets |
6 total |
| 120V 20A Outlets |
4 |
| 120V 30A Outlet |
1 (online UPS) |
| 120/240V 30A Outlet |
1 (backup UPS) |
| UPS Switchover |
Online UPS 0 ms, backup UPS under 20 ms |
| AC Output (Bypass Mode) |
100-120V, 50/60Hz, 30A total |
| Compressor Loads |
Up to 120A LRA or 20A RLA combined per unit |
| DC and USB Output |
| USB-C Outputs |
2 x 5/9/12/15/20V 5A, 100W max each |
| USB-C Total |
200W |
| USB-A Outputs |
2 x 5V 2.4A, 12W max each, 24W total |
| 12V DC Output |
12.6V 30A, 378W max |
| Charging Input |
| AC Charging Input |
100-120V 15A or 200-240V 12.5A, 50/60Hz |
| AC Charging Input Power |
1800W max at 120V, 3000W max at 240V |
| AC Input (Bypass Mode) |
100-120V 15A, 50/60Hz |
| Bypass Input Limit |
Under 3 hours when current exceeds 12A |
| Power Input/Output Port |
100-120V 30A or 200-240V 30A, 50/60Hz |
| High-PV Input |
80-450V, 15A max, 4000W max |
| Low-PV Input |
30-150V, 15A max, 1600W max |
| Total Solar Input |
5.6kW |
| PV Input Short-Circuit Current |
23A |
| EV Charging |
Up to 7.2kW |
| EV Charging Accessory |
EcoFlow EV X-Stream Adapter (sold separately) |
| Expansion |
| Batteries per Inverter |
Up to 5 |
| With Smart Home Panel 2 |
Up to 3 inverters and 15 batteries (about 90kWh) |
| Size and Weight |
| Inverter Dimensions |
27.2 x 18.9 x 8.4 in (690 x 481 x 214 mm) |
| Inverter Weight |
Approx. 70.8 lb (32.1 kg) |
| Battery Dimensions |
26 x 18 x 8 in (660 x 455 x 204 mm) |
| Battery Weight |
Approx. 111.3 lb (50.5 kg) |
| Environment |
| Charge Temperature |
-4°F to 113°F (-20°C to 45°C) |
| Discharge Temperature |
-4°F to 113°F (-20°C to 45°C) |
| Storage Temperature |
-4°F to 113°F (-20°C to 45°C) |
| Optimum Storage Temperature |
68°F to 86°F (20°C to 30°C) |
| IP Rating |
IP54 (protective covers closed) |
| Noise |
Under 30 dB in most scenarios |
| Altitude |
Up to 3000 m (9842 ft) |
| Connectivity |
| Wireless |
Wi-Fi and Bluetooth |
| 4G |
Port for EcoFlow 4G Dongle PPS (NA) |
| 4G Dongle |
Sold separately |
| 400W Portable Solar Panel (Each) |
| Rated Power |
400W (±10W) at STC |
| Open Circuit Voltage |
48V (Vmp 41V) |
| Short Circuit Current |
11A (Imp 9.8A) |
| Efficiency |
22.6% |
| Cell Type |
Monocrystalline silicon |
| Connector |
MC4 |
| Unfolded Dimensions |
41.7 x 93.1 x 1.0 in (105.8 x 236.5 x 2.5 cm) |
| Folded Dimensions |
41.7 x 24.4 x 1.0 in (105.8 x 62.0 x 2.5 cm) |
| Weight |
Approx. 35.3 lb (16.0 kg) |
| Kickstand Angle |
40° to 80° |
| Water and Dust Rating |
IP68 (lab tested, panel body only) |
| Operating Temperature |
-4°F to 185°F (-20°C to 85°C) |
| Warranty |
| DELTA Pro Ultra Inverter |
5 years |
| DELTA Pro Ultra Battery |
5 years |
| 400W Portable Solar Panel |
12 months |
